[oXygen-user] Insert Image as Variable in Eclipse environment

Mon Aug 31 00:53:23 CDT 2020

Hi Radu,

That’s it! Apparently I forgot how it worked. Thanks very much for your help.

Kind regards,

Judith

Judith Oudkerk | Technical Writer
ELEKTA | Nucletron
P.O. Box 930,
3900 AX, Veenendaal, The Netherlands
Visiting Address:
Waardgelder 1, 3905 TH Veenendaal
Judith.Oudkerk at elekta.com | www.elekta.com
Nucletron B.V., registered 2730 3235
Nucletron Operations B.V., registered 30129540
This message is confidential and may be legally privileged or otherwise protected from disclosure. If you are not the intended recipient, please telephone or email the sender and delete this message and any attachment from your system; you must not copy or disclose the contents of this message or any attachment to any other person.
Any views expressed in this message are those of the individual sender, except where the sender specifies and with authority, states them to be the views of Elekta. Elekta may monitor email traffic data.
From: oXygen-user <oxygen-user-bounces at oxygenxml.com> On Behalf Of Radu Coravu
Sent: maandag 31 augustus 2020 06:38
To: oxygen-user at oxygenxml.com
Subject: Re: [oXygen-user] Insert Image as Variable in Eclipse environment

Hi Judith,

Thank you for contacting us.

If you switch the opened DITA topic to the Text editing mode how does that image reference look like? Does it look like:
<image keyref="..."/>
?

The Oxygen Eclipse plugin should have for each opened DITA topic an "Insert image" toolbar action allowing you to insert either direct images or indirect (keyref) images.

If the toolbar action is not there for you, Ixiasoft may have changed this, they have access to our APIs and they can remove Oxygen actions which they consider that do not work well with their CMS. I think I saw a demonstration some years ago in which somebody from Ixiasoft used a special Ixiasoft side view in Eclipse to locate a key and then they right clicked and had options there to insert an image with a keyref, I think they also made this work with drag and drop, dropping the key definition in Oxygen's editing area.

If you will still have problems with this, maybe you should ask the Ixiasoft support about the recommended way to insert images in a DITA topic with the Oxygen integration.
Regards,
Radu

Radu Coravu

Oxygen XML Editor
On 8/28/20 5:08 PM, Oudkerk, Judith wrote:
Hi All,

I’m using Oxygen XML (version  in the Ixiasoft Eclipse CCMS environment. I’d like to insert an image as variable in a topic, but I can’t get it to work. I know it’s possible, because I used to do this in the Stand-alone Oxygen XML editor.

I created a variables map and added this for the image variable:
<keydef format="png" href="nlr1598608071706.image" keys="cap" scope="local"/>

The output shows the href as text though:

[cid:image001.jpg at 01D67F6B.CBB4A490]
Am I doing something wrong, or is it not possible within the Eclipse environment?

Version: Oxygen.3a (4.7.3a)
Build id: M20180330-0640

PS. The image is .PNG, not .SVG. This was just a test-topic I had lying around.

Thanks in advance for you input.
