[oXygen-user] [OXYGEN-22994] Suppressing Oxygen Error Messages for DITA Files with Base64-Encoded Images

[Frank Dissinger]

Hi Radu,



Thank you for your reply. You are right – it’s the extra space that causes the issue.

I didn't suspect it at first because because even though I removed that space several times, it keeps getting added back automatically by some action.

I will keep an eye on it to see what causes that space to get added.



Regards,
Frank





Von: oXygen-user <oxygen-user-bounces at oxygenxml.com> Im Auftrag von Oxygen XML Editor Support (Radu Coravu)
Gesendet: Dienstag, 17. Dezember 2024 13:37
An: oxygen-user at oxygenxml.com
Betreff: Re: [oXygen-user] [OXYGEN-22994] Suppressing Oxygen Error Messages for DITA Files with Base64-Encoded Images

Hello Frank,

I see you have an extra space in the "href" attribute value before the "data:" part, is it possible the error refers to that extra space in the href value?

If so you should remove that extra starting space from the @href value because the href attribute needs to contain an URI-like reference.

If not, would it be possible for you to send us directly (support at oxygenxml.com <mailto:support at oxygenxml.com> ) a small DITA topic containing such an image with which I could reproduce the problem?

Regards,

Radu

Radu Coravu
Oxygen XML Editor



---------------------------------------------------------------

On 12/17/24 11:49, Frank Dissinger wrote:

Hi list,



In one of my Oxygen projects, I need to generate an HTML file from DITA sources without using any external links. To achieve this, I embed a few icons directly into the output file using the following DITA code:






The … represents the remaining 1585 characters of the base64-encoded image data.



When I save the DITA file, Oxygen repeatedly displays the following error:





Description 



Severity 

Error 


Engine name 

DITA Validation 


Additional info 

 <https://www.oxygenxml.com/dita/1.3/specs/langRef/attributes/thehrefattribute.html> https://  www.oxygenxml.com/dita/ 1.3/specs/langRef/ attributes/  thehrefattribute.html 



Despite the error message, the HTML transformation works correctly, and the output file is generated as expected.

How can I prevent Oxygen from displaying these error messages?
