[oXygen-user] Error when transforming

Tue Oct 9 08:18:47 CDT 2018

Hi Rdu

I can understand this. What I find problematic that I can savely
transform the 700 pages book when I have changes docbook-custom.xsl, but
changing

the customization from

to

renders the transformation faulty. That in my opinion is the problem. It
has nothing to do with the modified xls stylesheet. And I am lost how
debug this since the error is erratic in my opinion besides fop not
giving any log.

Regards

Bernhard

Am 09.10.2018 um 14:44 schrieb Oxygen XML Editor Support (Radu Coravu):
> Hi Bernhard,
>
> As I previously said I do not have enough details on my side (the
> XSL-FO file on which the PDF processor is applied to produce the PDF
> or a sample Docbook XML + XSLT customization) in order to understand
> better what's going on.
>
> Regards,
> Radu
>
> Radu Coravu
> <oXygen/> XML Editor
> http://www.oxygenxml.com
>
> On 10/9/2018 1:23 PM, Bernhard Kleine wrote:
>> For the moment I have solved the problem by changing ..\Oxygen XML
>> Editor 20\frameworks\docbook\xsl\fo\docbook_custom.xsl and adding the
>> lines from my customization. This worked. Copying docbook_custom.xsl to
>> the xsl/fo/ subfolder of my project doesnot work since it links to
>> further stylesheets. Having docbook_custom.xsl added as another
>> stylesheet did not work since "cascading stylesheet" did not work.
>>
>> The error I reported has obviously nothing to do with the content of the
>> Buch.xsl stylesheet, but with the customization I have shown to you. I
>> am lost to see the reason for that.
>>
>> Regards
>>
>> Bernhard
>>
>>
>> Am 09.10.2018 um 07:26 schrieb Oxygen XML Editor Support (Radu Coravu):
>>> Hi Bernhard,
>>>
>>> If you publish to PDF without your customizations do you obtain the
>>> same problem?
>>> You will probably have to trim down your DocBook file to a minimum
>>> until you have a minimal sample with which the PDF processor problem
>>> can be reproduced. Then you can send it over to
>>> "support at oxygenxml.com" and we can take a look at it.
>>>
>>> Regards,
>>> Radu
>>>
>>> Radu Coravu
>>> <oXygen/> XML Editor
>>> http://www.oxygenxml.com
>>>
>>> On 10/8/2018 11:02 PM, Bernhard Kleine wrote:
>>>> I have analyzed the situation:
>>>>
>>>> When I transform the glossar of my book, transformation is without
>>>> trouble. However, when transforming the whole book plus the
>>>> glossar, it
>>>> stumbles
>>>>
>>>> I then analyzed the glossar: It has seven glossdivs. The last one
>>>> consists of some 20 glossdefs, of which I show the last ones:
>>>>
>>>>       <glossentry xml:id="glo.Tumor">
>>>>         <glossterm>Tumor</glossterm>
>>>>         <glossdef>
>>>>           <para>Als Tumor wird zunächst eine raumfordernde
>>>> Wucherung von
>>>> Zellen bezeichnet, ein
>>>>             synonymer Ausdruck ist Neoplasie. Dabei gibt es gutartige
>>>> Tumoren und bösartige. Je nach
>>>>             Ort der Geschwulst und nach Art des verdrängten und
>>>> geschädigten Gewebes können
>>>>             Krankheiten bis hin zum Tod entstehen. Bösartige Tumoren
>>>> sind die Ursache von Krebs, bei
>>>>             dem sich ausgehend von den ursprünglichen Tumorzellen
>>>> weitere Geschwulste (Metatasen) in
>>>>             anderen Körperregionen bilden.</para>
>>>>         </glossdef>
>>>>       </glossentry>
>>>>       <glossentry xml:id="glo.geneticCode" xreflabel="Glo.T
>>>> Genetischer
>>>> Code">
>>>>         <glossterm>Genetischer Code<indexterm>
>>>>             <primary>Genetischer Code</primary>
>>>>           </indexterm></glossterm>
>>>>         <glossdef>
>>>>           <para>
>>>>             <table frame="sides" rowsep="0" colsep="0"> [163
>>>> lines]
>>>>           </para>
>>>>         </glossdef>
>>>>       </glossentry>
>>>>     </glossdiv>
>>>>   </glossary>
>>>> </sect2>
>>>>
>>>> It is this table which made the transformation choke. But only in the
>>>> context of the book, not in the glossar itself. Can you please explain
>>>> to me what I do wrong and how to change the behaviour?
>>>>
>>>> I have changed the transformation scenario to:
>>>>
>>>>
>>>> and are using the following stylesheet:
>>>>
>>>> <?xml version="1.0" encoding="UTF-8"?>
>>>> <xsl:stylesheet
>>>>   xmlns:xsl="http://www.w3.org/1999/XSL/Transform"
>>>>   xmlns:fo="http://www.w3.org/1999/XSL/Format"
>>>>   xmlns:d="http://docbook.org/ns/docbook"
>>>>   version="1.0">
>>>>   <xsl:import
>>>> href="http://docbook.sourceforge.net/release/xsl-ns/current/fo/docbook.xsl"/>
>>>>
>>>>
>>>>      <xsl:param name="caption.align">justify</xsl:param>
>>>>
>>>>   <xsl:template match="d:mediaobject/d:caption">
>>>>     <fo:block role="caption">
>>>>       <xsl:if test="$caption.align = 'right' or
>>>>         $caption.align = 'left' or
>>>>         $caption.align = 'justify' or
>>>>         $caption.align = 'center'">
>>>>         <xsl:attribute name="text-align">
>>>>           <xsl:value-of select="$caption.align"/>
>>>>         </xsl:attribute>
>>>>       </xsl:if>
>>>>       <xsl:apply-templates/>
>>>>     </fo:block>
>>>>   </xsl:template>
>>>> </xsl:stylesheet>
>>>>
>>>> Regards
>>>> Bernhard
>>>>
>>>>
>>>> --
>>>> spitzhalde9
>>>> D-79853 lenzkirch
>>>> bernhard.kleine at gmx.net
>>>> www.b-kleine.com, www.urseetal.net
>>>> -
>>>> thunderbird mit enigmail
>>>> GPG schlüssel: D5257409
>>>> fingerprint:
>>>> 08 B7 F8 70 22 7A FC C1 15 49 CA A6 C7 6F A0 2E D5 25 74 09
>>>>
>>>>
>>>>
